156mm/156.75mm Mono Cell 3BB

Dimension : 156.75mm x 156.75mm ± 0.25mm Diagonal : 210mm ± 0.25mm (round chamfers) Thickness(Si) : 180 ± 20μm Front : Anisotropically texturized surface and dark silicon nitride anti-reflection coatings 1.4mm silver busbars Back : Full-surface aluminum back surface field 2.0mm (silver / aluminum) discontinuous soldering pads High conversion efficiencies resulting in superior power output performance Outstanding power output even in low light or high temperature conditions Optimized design for ease of soldering and lamination Long-term stability, reliability and performance Low breakage rate Uniform Color Made In Taiwan

Keywords：

156/156.75mm Mono Solar Cell 3BB

Subclassification：

Solar Cell
