PERC MONO SOLAR CELL 4 BUS BAR

Dimension : 156.75mm x 156.75mm ± 0.25mm Diagonal : 210mm ± 0.25mm (round chamfers) Thickness(Si) : 180 + 20 / -30μm Front : Anisotropically texturized surface and dark silicon nitride anti-reflection coatings 1mm silver busbars Back : Local aluminum back-surface field 2mm (silver / aluminum) discontinuous soldering pads High conversion efficiencies resulting in superior power output performance Outstanding power output even in low light or high temperature conditions Optimized design for ease of soldering and lamination Long-term stability, reliability and performance Low breakage rate Uniform Color Made In Taiwan

Keywords：

High Quality Mono Perc Solar Cell With 4 Bus Bar Made In Taiwan

Subclassification：

Solar Cell

Enquire Now
