PERC MONO SOLAR CELL 5 BUS BAR
Dimension : 156.75mm x 156.75mm ± 0.25mm Diagonal : 210mm ± 0.25mm (round chamfers) Thickness(Si) : 180 + 20 / -30μm Front : Anisotropically texturized surface and dark silicon nitride anti-reflection coatings 0.7mm silver busbars Back : Local aluminum back-surface field 1.7mm (silver / aluminum) discontinuous soldering pads High conversion efficiencies resulting in superior power output performance Outstanding power output even in low light or high temperature conditions Optimized design for ease of soldering and lamination Long-term stability, reliability and performance Low breakage rate Uniform Color
Keywords：
Subclassification：
Solar Cell
